MHA0420NSG5R6M

Inquiry

Download

Specifications

Download

Specifications

Attribute	Explain
Series name	MHA0420NSG SERIES
Length(mm)	4.4±0.35
Width(mm)	4.0±0.25
Height(mm)	1.8±0.2
Iductace(μH))	5.60±20%
DCR Max(mΩ)	150
Isat(A)	2.8
Irms(A)	1.8

Download

MHA0420NSG5R6M.pdf
